   Sound Dome Mini Amplifier
On Sale: Was $199  Now Only: $149.00



20-Watt per channel class AB Mini Amplifier

35 dB maximum gain with 2 x 10 watt output. Dual RCA, stereo mini jack and high-level inputs. High pass filter at 120 Hz to reduce bass distortion in smaller speakers. Aluminum housing with integrated heat sink. Power inputs include either three-pin Euroblock or barrel connector. 12-volt trigger for automatic on/off functions when source power is detected. Included accessory: universal pole- and surface-mount adaptor. Included SA202-RDT accessories: universal pole- and surface-mount adaptor, 15-volt power supply. Designed for the FP series speakers.




Frequency Response (-3 dB) 20 Hz–20 kHz (+/- .1 dB)
Power Per Channel 20 watts (4 ohm stereo),
10 watts (8 ohm stereo)
Signal to Noise 92 dB (100 Hz, 12 dB per
octave, 4 ohm, A-weighted)
Input Impedance 6k ohms
Max Gain 35 dB
Filters 120 Hz, 12 dB per octave
Height 31.2 mm (1.23 in.)
Width 101.1 mm (3.98 in.)
Length 123.6 mm (4.86 in.) including connectors
Packaging 1 per box – includes mounting
hardware and power supply
(SA202- RDT only)
Optional Accessory Rack mount adaptor (AC-SA202-RMA
PS-1530-RDT Power Supply.
Weight 0.25 Kg (0.55 lbs.) amp only
